TP-Link CPE605 5GHz 300 Mbps 23dBi

İşlemci

Qualcomm 560MHz CPU, MIPS 74Kc

Bellek

64MB DDR2 RAM,8MB Flash

Arabirim

1 10/100Mbps Shielded Ethernet Port (LAN/POE)
1 Reset Button

Güç Kaynağı

Passive Power over Ethernet via LAN (+4,5pins; -7,8pins)
Voltage range: 16-27VDC

Boyutlar ( W X D X H )

350 x 255 x 207 mm (13.8 x 10.0 x 8.1 in.)

Anten Kazancı

23dBi

Anten Beamwidth

7°(Azimuth), 10°(Elevation)

Koruma

15KV ESD Protection
6KV Lightning Protection

Muhafaza

Material: Outdoor PC stabilized plastic
Weatherproof: IP65 water and dust proof design

Kablosuz Standartlar

IEEE 802.11a/n

Tescilli Protokol

TDMA Mode (with Pharos MAXtream enabled)

Kablosuz Hızı

Up to 150Mbps (40MHz,Dynamic)
Up to 72.2Mbps (20MHz,Dynamic)
Up to 36.1Mbps (10MHz,Dynamic)
Up to 18.05Mbps (5MHz,Dynamic)

Frekans

5.15~5.85GHz

İletim Gücü

Max. 23dBm (Adjustable power by 1dBm)

IPv6

Yes

Ağ Yapılandırma

WAN: Static/Dynamic/PPPoE/L2TP/PPTP
LAN: Static/Dynamic/DHCP
Forwarding: ALG/UPnP/Virtual Server/Port Trigger
Security: SPI Firewall/ Ping Forbidden/DoS Protection
Access Control
Static Routing
Bandwidth Control
IP & MAC Binding

Kablosuz Konfigürasyonlar

Pharos MAXtream TDMA Technology
Selectable Channel Width: 5/10/20/40MHz
Auto Channel Selection
Transmit Power Control
Dynamic Frequency Selection(DFS)
WDS Enable/Disable
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption,
64/128/152-bit WEP Encryption
SSID Broadcast Enable/Disable
Multi-SSID with VLAN Tagging(AP Mode only)
Distance/ACK Timeout Setting
Wireless MAC Address Filter
Wireless Advanced:
Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
Long Range PtP

Yönetim

Discovery and Remote Management via Pharos Control application
HTTP/HTTPS Web-based management
System log
SNMP Agent(v2c)
Ping Watch Dog
Dynamic DDNS
SSH Server

Sistem Araçları

Indicators:Signal Strength/Noise/Transmit CCQ/CPU/Memory
Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
Spectrum Analyzer
Speed Test
Ping
Traceroute
Antenna Alignment

Sistem Düzeyindeki Optimizasyonlar

Optimized IGMP Snooping/Proxy for multicast applications

Sertifika

CE, FCC, RoHS, IP65

Paket İçeriği

Outdoor Wireless CPE
24V 0.25A Passive PoE Adapter
Pole Mounting Kits
AC Power Cord
Installation Guide

Sistem Gereksinimleri

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 10, Windows 8, Windows 7, MAC OS, NetWare, UNIX or Linux.
Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome, Safari, and Firefox. IE browsers are not recommended.

Ortam

Operating Temperature: -40℃~70℃ (-40℉~158℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~95% non-condensing
